Key Features

1. Intel Core Ultra 9/7/5 Series Processor, Single Socket LGA-1851(Intel® V1 Socket) supported, CPU TDP supports Up to 125W TDP

2. Up to 256GB Unbuffered ECC/non-ECC UDIMM, DDR5-5600MHz, in 4 DIMM slots

3. M.2 Interface: 1 PCIe 4.0 x4 and 1 PCIe 5.0x4 (support M.2 Form Factor 2280 only)

M.2 Form Factor: 2280/22110

M.2 Key: M-Key

4. 2 M.2 slots (1 PCIe 4.0 x4 from PCH, support 2280/22110, and 1 PCIe5.0 x4 from CPU, support 2280)

5. 2 PCIe 5.0 x16 slots,

1 PCIe 4.0 x4 slot

6. A 2.5 Gigabit LAN with Intel® Ethernet i226LM LAN controller

7. A 1 Gigabit LAN with Intel® Ethernet i219LM LAN controller [AMT/vPro]

8. 1 HDMI 2.1*, 1 DP 2.1**, 1 Thunderbolt™ 4.0 Type-C®

*Supports data rates of up to 10 Gbps **Supports data rates of up to 10 Gbps

9. Intel® W880 Controller for 8 SATA3 (6 Gbps) ports, RAID 0,1,5,10

10.Supports Thunderbolt 4

11. Onboard TPM2.0


Optimized Servers

SYS-532AW-C
