Key Features

1.AMD Ryzen™ Threadripper™ PRO 3000WX Series Processor, up to 64 Cores

2.Up to 256GB Unbuffered non-ECC UDIMM/

2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMS.

3.6 PCI-E 4.0 x16 slots

M.2 Interface: 4 PCI-E 4.0 x4 (Software RAID 0,1,5,10)

M.2 Form Factor: 2280, 22110

M.2 Key: M-key

U.2 Interface: 2 U.2 sockets (Software RAID 0,1)

4.4 SATA 3.0 6Gbps (Software Raid 0,1,5 & 10)

5.1x 10GBase-T LAN port,

1 GbE LAN port (shared with IPMI)

6.ASPEED AST2600 BMC graphics

7.1 USB 3.2 Gen2x2 port (Type C, 20Gbps),

5 USB 3.2 Gen2 ports

  (4 type A + 1 front type C header),

5 USB 3.2 Gen1 ports

  (3 type A + 2 via header),

2 USB 2.0 ports via header

8.1 COM port (rear),

TPM 2.0 header,

7.1 Channel HD Audio

9.10 fan header, 4-pin type fan header,

112V-power header for liquid cooling
