Kingston KF556C40BBK4-128 128G 5600M DDR5 CL40 DIMM K4 FURY Beast Black XMP

KF556C40BBK4-128

128GB (32GB 4G x 64-Bit x 4 pcs.)

DDR5-5600 CL40 288-Pin DIMM Kit

DESCRIPTION

Kingston FURY KF556C40BBK4-128 is a kit of four 4G x 64-bit (32GB) DDR5-5600 CL40 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components per module. Each module kit supports Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit capacity is 128GB. Each module has been tested to run at DDR5-5600 at a low latency timing of 40-40-40 at 1.25V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:

FACTORY TIMING PARAMETERS

• Default (JEDEC): DDR5-4800 CL40-39-39 @1.1V

• XMP Profile #1: DDR5-5600 CL40-40-40 @1.25V

• XMP Profile #2: DDR5-5200 CL40-40-40 @1.25V

• XMP Profile #3: DDR5-4800 CL38-38-38 @1.1V
